Agilent 8690 Series 10 Wireless Communications Test Set E5515C - Professional Network Testing Equipment for 5G, LTE, and IoT Applications in Labs & Field Work

Product Description

Per the Manufacturer:

The Agilent E5515C hardware platform for the 8960 Series 10 wireless communication test set offers mobile manufacturers immediate competitive advantages. Developed for high-volume, automated mobile phone manufacturing test, the proven 8960 wireless communications test set offers speed, accuracy, repeatability, multi-format capability, ease of programming, and format-flexible architecture. For the mobile manufacturer, this translates into lower test costs and higher production output to help meet customer demand for phones now and into the future.

Supports GSM/GPRS/EGPRS/E-EDGE, W-CDMA/HSPA/HSPA+, cdma2000?/1xEV-DO/eHRPD, TD-SCDMA/TD-HSDPA/TD-HSUPA, IS-95, TIA/EIA-136 and AMPS wireless device testing Software upgradeable for quick access to new functionality Integrate with WTM software for quick automation of RF and parametric tests Remotely controllable through GPIB interface 292 to 2700 MHz frequency range includes all commercial 3GPP and 3GPP2 frequency bands -110 to -13 dBm output level range with modulation VSWR <1.2;1:400 to 2000 MHz < +/-1.0 dB channel power measurement accuracy

frequency range: 292 to 2700 MHz output level range:-110 to -13 dBm VSWR <1.2:1 400 to 2000 MHz channel power measurement accuracy:< +/-1.0 dB Weight:31.8 kg

Tested and Working Unit in Fine Condition.
